Our observation and mini class ROVs (Remotely Operated Vehicles) are ideal for jobs where larger vehicles are unsuited or unnecessary. The vehicles are capable of working in open ocean, bays, inland waterways and pipelines at depths up to 1000ft. Capabilities include HD video and sonar inspection, object search and recovery and ultrasonic testing.
Seabotix vLBV300
Specifications
Maximum Operating Depth: 300 meters
Power Source: 2x 2000w Generators or 120v
Mission Duration: Indefinite
In-Air Weight: 40lbs (18kg)
Dimensions: 24x15x14 in (61x.38x36 cm)
Thrusters: 4x vectored 2x vertical
Tether: 350 meter copper
Navigation
USBL: TriTech Micron Nav
Compass: OS4000-T Compass
Depth Sensor: Depth sensor
Base Sensor Payload
Sonar: TriTech SeaPrince Scanning Sonar
Video: Standard definition navigation feed, GoPro mount
Lighting: 4x Deep Sea Power an Light variable intensity LED
Tilt Mechanism: (Camera, LEDs) 180º
Tools
2x arms, w/ interchangeable heads: Two pronged grabber, three pronged grabber, guillotine cutter
Recovery: Line canister lift systems
The vLBV 300 ROV is an observation class vehicle equipped with a camera, lights and scanning sonar for visual inspection and search. The scanning sonar’s range is effective to 45 meters for large objects and 20 meters for small to medium objects. It is operated from the surface and can continue to run so long as the operator and support vessel are able to stay on station. It is especially well suited for identifying objects indicated in the AUV sonar search that warrant a visual inspection and confirmation. It is equipped with a GoPro so that a high definition video record can be downloaded when the ROV is recovered.
Seabotix LBV 200
Specifications
Maximum Operating Depth: 200 meters
Power Source: 1x 2000w Generator or 120v
Mission Duration: Indefinite
In-Air Weight: 428lbs (13kg)
Dimensions: 21x10x10 in (53x25x25 cm)
Thrusters: 3x axial 1x vertical
Tether: 250 meter copper
Navigation
Compass: OS4000-T Compass
Depth Sensor: Depth sensor
Base Sensor Payload
Sonar: TriTech SeaPrince Scanning Sonar
Video: Standard definition color, low light B/W, GoPro mount
Lighting: 2x Deep Sea Power an Light variable intensity LED
Tilt Mechanism: (Camera, LEDs) 180º
Tools
1x arm, w/ interchangeable heads: Two pronged grabber, three pronged grabber, guillotine cutter
The LBV 200 ROV is a low logistics micro ROV ideal for visual inspections in confined spaces with limited room for maneuverability. It is ideal for small diameter pipeline inspection and performs best in bodies of water with limited current.
